SFP28_HCB_H
DescriptionValueUnitNoteConnector types2.92(F)Impedance50OhmInsulation Resistance1000MΩOperating FrequencyDC~40GHzDielectric Withstanding Voltage400VS11 <- 15dB@<25G；<-12dB@25
- 測試板： 28G模塊測試板
- 產品分類： 光模塊測試板（HCB）
- 型號： SFP28_HCB_H
- 售后及質量保證： 質保半年
Description | Value | Unit | Note |
2.92(F) | |||
Impedance | 50 | Ohm | |
Insulation Resistance | 1000 | MΩ | |
Operating Frequency | DC~40 | GHz | |
Dielectric Withstanding Voltage | 400 | V | |
S11 | <- 15dB@<25G； <-12dB@25~30G； <-8@30~40G； | Hz | |
Insertion Loss | -6 | dB | TBD |
Operating Temperature | -55~+125 | ℃ | |
Connector Material&Coat-Plating | |||
紙盒包裝
